Rev. 1.4 1.General Operation
Numerical value sign widow
This window displays a measured parameter, function setup, and the boundary of parameter values.
Menu selection by using Touch wheel key
As the key is turned to the right, the menu selection moves clockwise. As the key is turned to the left,
the menu selection moves counterclockwise. The menu selection is activated when you Touch
Wheel
key.
DEMO :
ON
KEY
SOUND:
ON
DISPLAY
USB
FILE
COPY
MAKER
SERVICE
PREV
MENU
MAIN
MENU
USER
SERVICE
Menu selection with arrows
Upward Movement: Turns the touch wheel key to the left.
Downward Movement: Turns the touch wheel key to the right.
Selection is made by touching the touch wheel key. One exits the menu after the selection.
> ADT
PED
NEO
ADMIT
TYPE:
ADT
DISCHARGE
PREV
MENU
MAIN
MENU
When moving the within the quadrilateral, the text color reverses, and the numeric value applies
immediately.
60
98
%SpO2
PR
150
50
BPM
100
90
