english
|
97
10 Technical data
Supply voltage
1×230 V ±10%, 50/60 Hz, PE
Motor protection
External motor protection is not required
Type of protection
IP 44 (EN 60529)
Winding category
Insulation category F
Temperature category
TF 110 (EN 60335-2-51)
Media temperature
+2°C to +110°C
The temperature of the medium must be higher than the am-
bient temperature to prevent condensation water from forming
in the terminal box and the stator.
Ambient temperature Media temperature
°C Min. °C Max. °C
0 2 110
15 15 110
30 30 110
35 35 90
40 40 70
If the medium temperature is below the ambient
temperature, the pump head and connector must
be set in the 6 o’clock position.
Ambient temperature 0°C to +40°C
Operating pressure Max. 10 bar, 102 m, 1 MPa
Inflow pressure
Media
temperature
Minimunm inflow pressure
[bar] [m] [MPa]
≤ +75 °C 0.05 0.5 0.005
+90 °C 0.28 2.8 0.028
+110 °C 1.08 10.8 0.108
Noise Sound pressure level under 43 dB(A)
Electromagnetic
compatibility
EMV guidelines (2004/108/EC)
Standards: EN55014-1:2006, EN55014-2:1997
EEI-values PrimAX xx-3 = EEI ≤ 0.15
PrimAX xx-4 = EEI ≤ 0.16
PrimAX xx-6 = EEI ≤ 0.17
PrimAX xx-8 = EEI ≤ 0.18
