49
2. RS485 connection using multicore control cable.
RS485 Connection - Via Junction Box - Camera with RS485 serial connector.
12V DC Power Adaptor
Multicore control cable
TX RX NC NC GND
RX+R X- TX+ TX- GND
RS
422
RS
232
Camera
with Serial Port
RS422 (A/B)
1 8
Toggle
RS422
A or B
3. RS485 Daisy Chain Multiple Cameras connection.
RS485 Daisy Chain Connection - Via Junction Box - Camera with RS485 Serial Port.
