Tally Light GPI I/O Connection
GPI Connection with RS422 VISCA Control Connection
Tally Light GPI Connection.
Video Switcher
Tally/contact signal
HDMI/SDI
RS422 control signal
GPI Connection with VISCA OVER IP Control Connection
Video Switcher
Tally/contact signal
HDMI/SDI
Remote control signal,
Network Cable CAT5/6
with VISCA OVER IP Control
