DB-300-916
Fig.11: FS102(P), FS152(P) .. FS5502(P)
Connection positions
1 Refrigerant inlet
2 Refrigerant outlet
3 Pressure gauge connection
4 Connection for pressure relief valve
5 Sight glass
6 Fixing
Tab.3: Connection positions
Dimensions (if specified) may have tolerances accord-
ing to ENISO13920-B.
The legend applies to all BITZER liquid receivers and
contains connection positions that do not exist in each
receiver series.
Fixing bracket
Last letter ''N'' = bottom
Last letters ''H'' & ''T'' = bottom & top
