DB-300-9 49
4.10 Anschlussmaße für Flüssigkeitssammler
Typen 1
Eintritt Ø
2
Austritt Ø
3
Manometer
4
Druckentlas-
tungsventil
6
Befesti-
gung Ø
mm Zoll mm Zoll
F062H(P) 12 1/2 10 3/8 7/16 -20 UNF Innengewinde:
3/8 -18 NPTF
Außengewinde:
1 1/4 -12 UNF
9
F102H(P) 16 5/8 12 1/2 7/16 -20 UNF s.o. 9
F152H(P) 22 7/8 16 5/8 7/16 -20 UNF s.o. 9
F182 16 5/8 16 5/8 7/16 -20 UNF s.o. 9
F192T(P) 16 5/8 16 5/8 7/16 -20 UNF s.o. 9
F202H(P) 22 7/8 22 7/8 7/16 -20 UNF s.o. 9
F202HA DN 20 7/8 DN 20 7/8 - s.o. 9
F252H(P) 22 7/8 22 7/8 7/16 -20 UNF s.o. 9
F302G 42 1 5/8 42 1 5/8 7/16 -20 UNF s.o. 9
F302H(P) 22 7/8 22 7/8 7/16 -20 UNF s.o. 9
F302K 2 x 22 2 x 7/8 22 7/8 7/16 -20 UNF s.o. 9
F312 22 7/8 22 7/8 7/16 -20 UNF s.o. 9
F392T(P) 22 7/8 22 7/8 7/16 -20 UNF s.o. 9
F402H(P) 28 1 1/8 28 1 1/8 7/16 -20 UNF s.o. 9
F402HA DN 25 1 1/8 DN 25 1 1/8 - s.o. 9
F552T(P) 28 1 1/8 28 1 1/8 7/16 -20 UNF s.o. 9
F562G 54 2 1/8 42 1 1/8 7/16 -20 UNF s.o. 13
F562K 2 x 22 2 x 7/8 22 7/8 7/16 -20 UNF s.o. 13
F562N 35 1 3/8 28 1 1/8 7/16 -20 UNF s.o. 9
F562NP 42 1 5/8 35 1 3/8 - s.o. 9
F562NA DN 40 1 5/8 DN 32 1 3/8 - s.o. 9
F732N 35 1 3/8 28 1 1/8 7/16 -20 UNF s.o. 9
F732NP 42 1 5/8 35 1 3/8 - s.o. 9
F902N 42 1 5/8 35 1 3/8 7/16 -20 UNF s.o. 9
F902NP 42 1 5/8 35 1 3/8 - s.o. 9
F1052G 54 2 1/8 42 1 5/8 7/16 -20 UNF s.o. 13
F1052K 2 x 22 2 x 7/8 22 7/8 7/16 -20 UNF s.o. 13
F1052T 42 1 5/8 35 1 3/8 7/16 -20 UNF s.o. 9
F1052TP 42 1 5/8 35 1 3/8 - s.o. 9
F1052TA DN 40 1 5/8 DN 32 1 3/8 - s.o. 9
F1202N 54 2 1/8 42 1 5/8 7/16 -20 UNF s.o. 13
F1202NP 54 2 1/8 42 1 5/8 - s.o. 13
F1602G 76 3 1/8 54 2 1/8 7/16 -20 UNF s.o. 13
F1602K 2 x 28 2 x 1 1/8 28 1 1/8 7/16 -20 UNF s.o. 13
F1602N 54 2 1/8 42 1 5/8 7/16 -20 UNF s.o. 13
F1602NP 54 2 1/8 42 1 5/8 - s.o. 13
