DB-300-950
Typen 1
Eintritt Ø
2
Austritt Ø
3
Manometer
4
Druckentlas-
tungsventil
6
Befesti-
gung Ø
F1602NA DN 50 2 1/8 DN 40 1 5/8 7/16 -20 UNF s.o. 13
F2202N(P) 76 3 1/8 54 2 1/8 1/4 -18NPTF s.o. 13
F3102N(P) 76 3 1/8 54 2 1/8 1/4 -18NPTF s.o. 13
F3102NA DN 80 3 1/8 DN 50 2 1/8 1/4 -18NPTF s.o. 13
FS33 10 3/8 10 3/8 7/16 -20 UNF s.o. M10
FS36(P) 10 3/8 10 3/8 7/16 -20 UNF s.o. M10
FS48 10 3/8 10 3/8 7/16 -20 UNF * 13
FS48P 10 3/8 10 3/8 7/16 -20 UNF s.o. 13
FS53 12 1/2 10 3/8 7/16 -20 UNF s.o. M10
FS56(P) 10 3/8 10 3/8 7/16 -20 UNF s.o. M10
FS68 12 1/2 12 1/2 7/16 -20 UNF * 13
FS68P 12 1/2 12 1/2 7/16 -20 UNF s.o. 13
FS76(P) 12 1/2 12 1/2 7/16 -20 UNF s.o. 13
FS78 12 1/2 12 1/2 7/16 -20 UNF * 13
FS83 16 5/8 12 1/2 7/16 -20 UNF s.o. M10
FS102(P) 16 5/8 12 1/2 7/16 -20 UNF s.o. 13
FS126(P) 12 1/2 12 1/2 7/16 -20 UNF s.o. 13
FS128 16 5/8 12 1/2 7/16 -20 UNF * 13
FS128P 16 5/8 12 1/2 7/16 -20 UNF s.o. 13
FS152(P) 22 7/8 16 5/8 7/16 -20 UNF s.o. 13
FS188 16 5/8 16 5/8 7/16 -20 UNF * 13
FS202(P) 22 7/8 22 7/8 7/16 -20 UNF s.o. 13
FS252(P) 22 7/8 22 7/8 7/16 -20 UNF s.o. 13
FS268(P) 22 7/8 22 7/8 7/16 -20 UNF s.o. 13
FS302(P) 28 1 1/8 22 7/8 7/16 -20 UNF s.o. 13
FS302K 2 x 22 2 x 7/8 22 7/8 7/16 -20 UNF s.o. 13
FS402(P) 28 1 1/8 22 7/8 7/16 -20 UNF s.o. 13
FS562 35 1 3/8 28 1 1/8 7/16 -20 UNF s.o. 13
FS562K 2 x 22 2 x 7/8 22 7/8 7/16 -20 UNF s.o. 13
F562P 42 1 5/8 35 1 3/8 - s.o. 13
FS732 35 1 3/8 28 1 1/8 7/16 -20 UNF s.o. 13
FS732P 42 1 5/8 35 1 3/8 - s.o. 13
FS902 42 1 5/8 35 1 3/8 7/16 -20 UNF s.o. 13
FS902K 2 x 22 2 x 7/8 22 7/8 7/16 -20 UNF s.o. 13
FS902P 42 1 5/8 35 1 3/8 - s.o. 13
FS1122 54 2 1/8 42 1 5/8 7/16 -20 UNF s.o. 13
FS1122P 54 2 1/8 42 1 5/8 - s.o. 13
FS1602 54 2 1/8 42 1 5/8 7/16 -20 UNF s.o. 13
FS1602K 2 x 28 2 x 1 1/8 28 1 1/8 7/16 -20 UNF s.o. 13
FS1602P 54 2 1/8 42 1 5/8 - s.o. 13
FS2202(P) 76 3 1/8 54 2 1/8 1/4 -18 NPTF s.o. 13
