DB-300-9 19

Types 1

Inlet diameter

Outlet diameter

Pressure gauge

Pressure relief

valve

Fixing

dia-

meter

FS1602P 54 2 1/8 42 1 5/8 - see above 13

FS2202(P) 76 3 1/8 54 2 1/8 1/4 -18 NPTF see above 13

FS3102(P) 76 3 1/8 54 2 1/8 1/4 -18 NPTF see above 13

FS4002(P) DN 100 76 3 1/8 1/4 -18 NPTF see above 18

FS4752(P) DN 100 76 3 1/8 1/4 -18 NPTF see above 18

FS5502(P) DN 100 76 3 1/8 1/4 -18 NPTF see above 18

* Connection for pressure relief valve upon request.

Tab.4: Connection dimensions for liquid receivers
