DB-300-926
Types 1 Ø 2 Ø 3 Ø 4 Ø 5 6 7 9* 12
Ø
OAHC65051A DN 125 DN 125 DN 50 DN 25 DN 25 3/8 -
18NPTF
3/8 -
18NPTF
DN 25 -
OAHC80051A DN 150 DN 150 DN 65 DN 25 DN 25 3/8 -
18NPTF
11/8 -
18UNEF
DN 32 -
OAHC100051A DN 200 DN 200 DN 65 DN 25 DN 25 3/8 -
18NPTF
11/8 -
18UNEF
DN 32 -
* External thread: 1 1/4 -12 UNF, internal thread: 3/8 18 NPTF
Tab.6: Connection dimensions for oil separators
