Display
16-character fluorescent display for showing measurements and programmed values.
Annunciators
Annunciators light to indicate operating modes and status conditions:
OFF
power off
Trigger
Indicates that the electronic load is
waiting an initiate and trigger to
occur.
CC
The selected input channel is in
the constant current (CC) mode.
Sense
Indicates that the electronic load is
in sense state
CV
The selected input channel is in
the constant voltage (CV) mode.
Error
A errors have occurred
CW
The selected input channel is in
the constant power (CW) mode.
Link
In the communication state
CR
The selected input channel is in
the resistance (CR) mode.
Rmt
Indicates that the electronic load is
in remote state (RS-232). In the
remote state, only the active key is
the Local key.
Tran
The selected input channel is
enabled for transient operation.
Shift
Indicates that the shift key has been
pressed.
List
A list is initiated or running.
Lock
keyboard is the mode for password
Function keys
Main Function:
Set up a constant current output.
Set up a constant power output.
Set up a constant resistance output
Select CC, CR and CV and CW modes.
Select Current, Resistance and Voltage levels.
Set Trigger and Transient levels.
Set up front panel measurements.
Recall the stored data
Battery testing
Short-circuit testing
