43
Remote Operation Mode
DB9 in the rear panel of electronic load could connect with RS-232
through on TTL connector. The following information may help you to
know how to control the output of Electronic load through PC.
1. Communication Setting
Ensure setting the same baud rate in the communication address of
Electronic load and computer software .otherwise, the communication will fail.
You can adjust the baud rate and communication address in Menu button in
front panel of machine. Address of the Electronic load. ( 0 ~ 0XFE, default
value is 0)
1. Baud rate : (4800,9600,19200,38400, default value is 9600)
2. Data bit : 8
3. Stop bit : 1
4. sum: (NONE,ODD,EVEN,INITIAL SETTING is NONE)
Start
Bit
8 Data Bits
Stop
Bit
PARITY = NONE
2. DB9 Interface Details
DB9 in the rear panel of electronic load is TTL (5V) level signal .it can be
connecting with standard PC interface through the IT-E131 isolated
communication cable.
To Next Page
