BK Precision 8500 Series User Manual

42
Specifications
Parameter
8500
Voltage 0 to 120V
Current 1mA to 30A
Input rating
( 0 ~ 40 ? )
Power 300 W
Range Accuracy Resolution
0-18V
±(0.05%+0.02%FS)
1mV
0-120V / 500V
±(0.05%+0.025%FS)
10mV
0-3A
±(0.1%+0.1%FS)
0.1mA
Load
Regulation
0-30A / 15A
±(0.2%+0.15%FS)
1mA
1.5-18V
±(0.05%+0.02%FS)
1mV CV Mode
Regulation
1.5-120V/500V
±(0.05%+0.025%FS)
10mV
0-3A
±(0.1%+0.1%FS)
0.1mA CC Mode
Regulation
0-30A /15A
±(0.2%+0.15%FS)
1mA
0.1-10O ±(1%+0.3%FS) 0.001O
10-99O ±(1%+0.3%FS) 0.01O
100-999O ±(1%+0.3%FS) 0. 1O
CR Mode
Regulation
Input current =FS
10%
Input Voltage=FS
10%
1K-4KO ±(1%+0.8%FS) 1O
0-100W
±(1%+0.1%FS)
1mW CW Mode
Regulation
Input current =FS
10%
Input Voltage=FS
10%
100-300W
±(1%+0.1%FS)
10mW
0-3A
±(0.1% + 0.1%FS)
0.1mA Current
Measurement
0-30A /15A
±(0.2%+0.15%FS)
1mA
1.5-18V
±(0.02% + 0.02%FS)
1mV Voltage
Measurement
1.5-120V/500V
±(0.02% + 0.025%FS)
10mV
0-100W
±(1%+0.1%FS)
1mW Power
Measurement
Input current=FS
10%
Input Voltage=FS
10%
100-300W
±(1%+0.1%FS)
10mW
Battery testing
function
Input=0.8-120V / 500V Max measurement
capacity= 999A/H Resolution =10mA
Timer range=1~60000sec
Transition Mode
Range o Frequency 0.1Hz
-1kHz Frequency error rate< 0.5%
Weight 11.6lb. (5.25 kg)

BK Precision 8500 Series Specifications

General

Series	8500
Voltage Range	0-120V
Display	LCD
Interface	USB, RS232, GPIB (optional)
Modes	CC, CV, CR
Category	Electronic Load
