BK Precision 8500 Series User Manual

41
2) Press
Shift
and
Menu
, move cursor to the option of menu of CONFIG ,
Press
ENTER
into the next step menu ,move cursor to TRIGGER
SOURCE . Press
ENTER
and move cursor to IMMEDIATE <DEF>, setting
trigger source mode is panel IMMEDIATE mode.
3) Press
ENTER
to confirm.
4) Press
ESC
to the previous menu , move cursor to LIST SET .
5) Press
ENTER
into the next step menu .move cursor to EDIT LIST FILE.
6) Press
ENTER
into the next step menu, move cursor to CURRENT LIST,
select CURRENT MODE.
7) Press
ENTER
, move cursor to REPEAT . Setup LIST is in cycle mode.
8) Press
ENTER
to confirm, setup the list steps = 5.
9) Press
ENTER
to confirm, setup step 1 current =3A.
10) Press
ENTER
to confirm, setup step 1 width=6mS.
11) Repeat 7) and 8) operation , set current and width of one step 0A, 5mS;2A,
4mS;6A,2mS;0A,5mS.
12) Press
ENTER
to confirm, Menu STORE LIST FILE 1. save file in group1.
13) Move cursor to Mode Set , press
ENTER
to enter into the next step menu to
set mode is <LIST MODE >
14) Press
ENTER
to confirm
15) Press
ESC
, Press
Input on/off
, Make Load in ON state.
16) Press
Shift
and
Trigger
, make list operation run or stop.
17) Stop the list operation mode. Move cursor to LIST SET , Press
ENTER
,
move cursor to Mode Set in option menu, press
ENTER
, Enter into next
step menu . Select mode is <FIXED MODE> ?
18) Press
ENTER
to confirm.

BK Precision 8500 Series Specifications

General

Series	8500
Voltage Range	0-120V
Display	LCD
Interface	USB, RS232, GPIB (optional)
Modes	CC, CV, CR
Category	Electronic Load
