44
4. While 12V or 24V is flashing, use keys to toggle between the two options. Set to
12V for the 12V test function and 24V for the 24V test function.
5. Use the key to select Off/On and use keys to toggle between the two options.
Choose On to be able to run the function.
6. Once both parameters are set, press to confirm the changed settings and press
twice to exit the menu. If the DIN40839 function was setup properly, the Trig
indicator will be highlighted and DIN40839 will be shown on the front panel, shown
below.
7. To enable the DIN40839 function, press the key, on the front panel. The proper
voltage (12V or 24V) should be metered on the front panel display.
8. To run the DIN40839 function press shift and enter to trigger the test to run.
9. Repeat step 8 to trigger the function to run as many times as needed.
ISO 16750-2 Parameters
The ISO16750-2 function contains three different test simulations, Short voltage drop, Profile
for the reset test, and Starting profile. All three test simulations are based on the ISO 16750-2
requirements and applies to electric and electronic systems/components for vehicles. The pulse
shapes and parameters are shown below:
