6 Specifications
Note: All specifications apply to the unit after a temperature stabilization time of 15 minutes over an ambient
temperature range of 23 °C ± 5 °C. Specifications are subject to change without notice.
Envi
ronmental Conditions:
This power supply is designed for indoor use and operated with maximum relative humidity of 95%.
Model
9115 / 9115-AT
9116
Output Rating
Voltage
0 – 80 V
0 – 150 V
Current
0 – 60 A
0 – 30 A
Max Output Power
1200 W
Load Regulation
(1) (2)
Voltage
0.01 % + 5 mV
Current
0.1 % + 10 mA
Line Regulation
(2)
Voltage
0.02 % + 1 mV
Current
0.02 % + 1 mA
Programming/Readback Resolution
Voltage
1 mV
3 mV
Current
1 mA
1 mA
Programming/Readback Accuracy
(2)
Voltage
0.02 % + 30 mV
0.05 % + 30 mV
Current
0.1 % + 60 mA
0.2 % + 30 mA
Ripple (20 Hz – 20 MHz )
Voltage
≤ 60 mVpp
Current
100 mArms
50 mArms
Temperature Coefficient
(0 °C – 40 °C)
(2)
Voltage
0.02 % + 30 mV
Current
0.05 % + 10 mA
Readback Temperature Coefficient
(0 °C – 40 °C)
(2)
Voltage
0.02 % + 30 mV
Current
0.05 % + 5 mA
Efficiency
73% (120 VAC)
75% (220 VAC)
75% (120 VAC)
80% (220 VAC)
Power Factor
0.99 (full load)
Input Current (nominal)
13.8 A @ 120 VAC
7.3 A @ 220 VAC
13.3A @ 120 VAC
6.9 A @ 220 VAC
AC Input
115/230 VAC ± 10 %, 47 Hz – 63 Hz
Standard Interface
USBTMC, GPIB, RS-232, RS-485
Dimensions (WxHxD) (mm)
414.5 x 44.5 x 483.2
Weight
8.5 kg
Operating Temperature
0 °C – 40 °C
Storage Temperature
-20 °C – 70 °C
(1)
With remote sense connected
(2)
Accuracy specified as ±(% of output + offset) after a temperature stabilization time of 15 minutes over an
ambient temperature range of 23 ºC ±5 ºC
