1.5 Rear Panel Overview
Rear Panel Description
Analog Control Interface
Output Terminal
Rear Cooling Fan
GPIB Interface
USB Interface
RS-232 Interface
AC Input Receptacle
Fuse Box
RS-485 Interface
Remote Sense Terminals
1
2
3
3
4
5
6
7
8
9
10
1
2
3
4
5
6
7
8
9
Figure 1.4 - Rear Panel for 9115/9115-AT/9116
