17
5. To disable OVP at any time, just press twice. When it is disabled, the backlight
will disappear.
When OVP protection is tripped, the following screen will display:
To clear the trip status, press once.
Configure Maximum Power Limit
Follow the steps below to set the maximum power limit:
1. Press and then . The display will show P
max
on the bottom right. Use
the voltage or current adjust knob or the numeric keypad to enter the maximum power
output limit.
2. Press to save the change.
3. Use the voltage or current adjust knob or the numeric keypad to enter a value. This can
be from 1 ms – 600 ms.
4. Press to save the change. OVP is now configured. Notice the backlight
will turn on. This means OVP is enabled.
5. To disable OVP at any time, just press twice. When it is disabled, the backlight
will disappear.
When the output reaches the power maximum limit, the over power protection is tripped and
the following screen will display:
