BK Precision 9200B Series User Manual

31
Standard event status register
Bit
Decimal
Value
Definition
0
OPC
1
Operation Complete. All commands prior to and including
an *OPC command have been executed.
1
Not used
0
Always set to 0.
2
QYE
4
Query Error. The power supply tried to read the output
buffer but it was empty. Or, new command line was
received before a previous query had been read. Or, both
the input and output buffers are full.
3
DDE
8
Device Error. A self-test or calibration error occurred (see
error numbers 601 through 750 in chapter 5).
4
EXE
16
Execution Error. An execution error occurred (see error
numbers -211 through -224 in chapter 5).
5
CME
32
Command Error. A command syntax error occurred (see
error numbers -101 through -178 in chapter 5).
6
Not used
0
Always set to 0.
7
PON
128
Power On. Power has been turned off and on since the
last time the event register was read or cleared
Query status register
Bit
Decimal
Value
Definition
0
Voltage
1
The power supply is/was in the constant current
mode. Only registers whenever the power supply
enters into CV (voltage) or CC (mode). It will not
constantly return these bit values when you are in
the mode.
1
Current
2
The power supply is/was in the constant current
mode. Only registers whenever the power supply
enters into CV (voltage) or CC (mode). It will not
constantly return these bit values when you are in
the mode.
2-3
Not used
0
Always set to 0.
4
Overtemperature
16
The fan has a fault condition.
5-8
Not used
0
Always set to 0.
9
Overvoltage
512
The overvoltage protection circuit has tripped.
10
Not used
0
Always set to 0.
11
Overcurrent
1024
The overcurrent protection circuit has tripped.
12-15
Not used
0
Always set to 0.
