6. (Optional) You may also verify the output voltage and frequency by connecting the (L)
and (N) terminals on the rear panel to an external multi-meter or an oscilloscope.
Under normal operation, the measured value will be equal to or within the entered
voltage and frequency value.
7. Ensure that the voltage can be adjusted from zero to the full rated output of the unit
and verify the full frequency range is within specifications.
Check Model and Firmware Version
The model and firmware version can be verified by using the *IDN? query remote command. It
can also be found from within the menu system by following these steps:
1. Press (Shift) and press (Menu) to enter the menu system.
2. Press the arrow two times until INFO is blinking. Press
, and the display
will show the following screen:
3. The model is shown above as 9801, and the firmware version is shown as 0.02 – 0.01.
4. Press to exit the menu and return to the normal display.
Model: 9801 Ver: 0.02 – 0.01
