6 Specifications
Note: All specifications apply to the unit after a temperature stabilization time of 15 minutes over an ambient
temperature range of 25 °C ± 5 °C. Specifications are subject to change without notice.
Model
9801
9803
9805
AC Input
Phase
Single
Voltage
110 / 220 VAC ± 10%
Frequency
47 – 63 Hz
Current
8 A max.
15 A max
30 A max
Power Factor
0.5 (typical)
0.7 (typical)
0.7 (typical)
AC Output
Max. Power
300 VA
750 VA
1500 VA
Max Current
(rms)
0 – 150 V
3 A
6 A
12 A
0 – 300 V
1.5 A
3 A
6 A
Max Current
(Peak)
0 – 150 V
12 A
24 A
48 A
0 – 300 V
6 A
12 A
24 A
Phase
Single
Total Harmonic
Distortion (T.H.D)
≤ 0.5% at 45 – 500 Hz (Resistive Load)
Line Regulation
0.1 % max for a ± 10% line change
Load Regulation
≤ 0.5% FS (Resistive Load)
Response Time
< 100 μs
Programming
Voltage
(rms)
Range
0 – 300 V, 150 / 300 V (Auto)
Resolution
0.1 V
Accuracy
± (0.2% + 0.6 V)
Frequency
Range
45 – 500 Hz
Resolution
0.1 Hz at 45 – 99.9 Hz
1 Hz at 100 – 500 Hz
Accuracy
± 0.1 Hz (< 100 Hz)
± 1 Hz (100 – 500 Hz)
Phase
Angle
Range
0 – 360 °
Resolution
0.1 °
Accuracy
± 1° (45 – 65 Hz)
Measurement
Voltage
(rms)
Range
0 – 300 V
Resolution
0.1 V
Accuracy
± (0.2% + 0.6 V)
Current
(rms)
Range*
Low: 120 mA / Mid: 1.2 A
High: 3 A*
Low: 120 mA/Mid: 1.2 A
High: 6 A*
Low: 120 mA / Mid: 1.2 A High:
12 A*
Resolution
Low: 0.1 mA / Mid: 1 mA / High: 10 mA
Accuracy
Low: ± (0.2% + 0.4 mA) / Mid: ± (0.2% + 4 mA) / High: ± (0.2% + 20 mA)
Current
(peak)
Range
0 – 12 A
0 – 24 A
0 – 48 A
Resolution
0.01 A
Accuracy
± (1% + 120 mA)
True
Resolution
L: 0.01 W / M: 0.1 W / High: 1 W
