APPENDIX A: EMERALD SE VIDEO RESOLUTIONS SUPPORTED
The Emerald SE supports the resolutions listed below:
 640 x 480 @ 60 Hz
 640 x 480 @ 75 Hz
 800 x 600 @ 60 Hz
 800 x 600 @ 70 Hz
 800 x 600 @ 72 Hz
 800 x 600 @ 75 Hz
 800 x 600 @ 85 Hz
 1024 x 768 @ 60 Hz
 1024 x 768 @ 75 Hz
 1024 x 768 @ 85 Hz
 1280 x 800 @ 60 Hz
 1280 x 960 @ 60 Hz
 1280 x 960 @ 85 Hz
 1280 x 1024 @ 60 Hz
 1280 x 1024 @ 75 Hz
 1280 x 1024 @ 85 Hz
 1366 x 768 @ 60 Hz
 1400 x 1050 @ 60 Hz
 1440 x 900 @ 60 Hz
 1600 x 900 @ 60 Hz
 1680 x 1050 @ 60 Hz
 1600 x 1200 @ 60 Hz
 1680 x 1050 @ 60 Hz
 1280 x 720 @ 60 Hz
 1920 x 1080 @ 60Hz
 1920 x 1200 @ 60 Hz
Emerald SE also will pass all the above resolutions at refresh frequencies from 15 Hz to 60 Hz. Those with non-defined VESA
resolutions will be displayed at 60 Hz even if the incoming resolution is not 60 Hz.
