CHAPTER 1: SPECIFICATIONS
1.1 GENERAL SPECIFICATIONS
TABLE 1-1. SPECIFICATIONS
SPECIFICATION DESCRIPTION
Approvals
Unit FCC, CE, CSA, RoHS, WEEE
Power Supply TUV, UL
Physical
LED Interface
(1) Power LED button (deactivated, not used);
NOTE: Unit automatically powers on when plugged in; must be powered off at the power source.
(1) RJ-45 Speed LED (green, located on top left of RJ-45 connector):
Blinks three times when the network connection is 1000 Mbps,
Blinks two times when network connection is 100 Mbps,
Blinks once when the network connection is 10 Mbps,
Not blinking: No Link to network;
(1) Activity LED (green, located on top right of RJ-45 connector):
Solid green: Link up,
Blinking: Activity on the link,
OFF: No link
Maximum Distance from CPU
to Transmitter
EMD2000SE-T: 16 ft. (5 m), DVI-D and USB limitations
Maximum Distance between
Transmitter and Receiver
328 ft. (100 m), use a network switch to get farther distances
Operating System Support
Microsoft Windows
®
Vista, XP, Windows 7, Windows 8, Windows 10, Server 2003, Server 2008, Server 2012, LInux
®
,
Solaris, Mac OS
Connectors
EMD2000SE-T: (1) DVI input, (1) USB Type B female, (1) RJ-45 network, (1) RJ-45 serial, (2) 3.5 mm audio,
(1) 2.5 mm barrel for power;
EMD2000SE-R: (1) DVI output, (4) USB Type A female, (1) RJ-45 network, (1) DB9 serial,
(2) 3.5 mm audio for SPK and MIC, (1) 2.5 mm barrel for power;
EMD2002SE-T: (2) DVI input, (1) USB Type B female, (1) RJ-45 network, (1) RJ-45 serial, (2) 3.5 mm audio,
(1) 2.5 mm barrel for power;
EMD2002SE-R: (2) DVI output, (4) USB Type A female, (1) RJ-45 network, (1) DB9 serial,
(2) 3.5 mm audio for SPK and MIC, (1) 2.5 mm barrel for power
Dimensions
EMD2000SE-T, EMD2000SE-R: 1.15" H x 6.2" W x 4.2" D (2.92 x 15.75 x 10.67 cm);
EMD2002SE-T: 1.43” H x 6.2” W x 4.2” D (3.65 x 15.75 x 10.67 cm);
EMD2002SE-R: 1.15” H x 6.2” W x 4.2” D (2.92 x 15.75 x 10.67 cm)
Weight
EMD2000SE-T, EMD2000SE-R: 1.18 lbs (0.54 kg);
EMD2002SE-T: 1.47 lb. (0.67 kg);
EMD2002SE-R: 1.36 lb. (0.62 kg)
Operation
Default IP Address
EMD2000SE-T, EMD2002SE-T: 192.168.1.22;
EMD2000SE-R, EMD2002SE-R: 192.168.1.21
Encryption Secure Sockets Layer (SSL) over TCP/IP, 128-bit between TX and RX, user set between RX and Hyper-V
Default Username admin
Default Password The password is blank by default
DDC Support Built-in/clone of remote
Switching Time <1 sec
