The Contemporary by Blaze King Owners Installation and Operation Manual
Installation Instructions
SIMPSON DURAVENT DIRECTVENT PRO / GS SYSTEM PARTS LIST
Description Part # Old Part #
Horizontal Termination Kit - In Canada—Mandatory to add a wall thimble
(46DVA-KHC.)
46DVA-KHA 971
Vertical Termination Kit - 978
6” Pipe Length -Black 46DVA-06B 908B
6” Pipe Length –Galvanized 46DVA-06 908
8,5” Black Extension (3”-7”) 46DVA-08AB -
8,5” Galvanized Extension (3”-7”) 46DVA-08A -
9” Pipe Length-Black 46DVA-09B 907B
9” Pipe Length-Galvanized 46DVA-09 907
12” Pipe Length-Black 46DVA-12B 906B
12” Pipe Length-Galvanized 46DVA-12 906
16” Black Extension (3”-14.5”) 46DVA-16AB -
16” Galvanized Extension (3”-14.5”) 46DVA-16A -
24” Pipe Length-Black 46DVA-24B 904B
24” Pipe Length-Galvanized 46DVA-24 904
36” Pipe Length-Black 46DVA-36B 903B
36” Pipe Length-Galvanized 46DVA-36 903
48” Pipe Length-Black 46DVA-48B 902B
48” Pipe Length-Galvanized 46DVA-48 902
11”- 14 5/8” Adjustable Pipe Length-Black - 911B
17”- 24” Adjustable Pipe Length-Black - 917B
45° Elbow-Black 46DVA-E45B 945B, 945BG
45° Elbow-Galvanized 46DVA-E45 945, 945G
90° Elbow-Galvanized 46DVA-E90 990, 990G
90° Elbow-Black 46DVA-E90B 990B, 990BG
Vertical High Wind Termination Cap (must be used for all vertical terminations) 46 DVA-VCH 991
Horizontal. DV Termination with 1” return - 984GL
Horizontal. Square Termination Cap - 984
Horizontal. Square High Wind Termination Cap 46DVA-HC 985
Horizontal Round Termination Cap 46DVA-HRCS -
Sconce Termination Cap 46DVA-HSC -
Wall Thimble Cover—Support Box 46DVA-DC 940
Cathedral Ceiling Support Box 46DVA-CS 941
Brass Trim fro Ceiling Support Box - 3951
Firestop Spacer 46DVA-FS 963
Flashing 0/12-6/12 46DVA-F6 943
Flashing 7/12-12/12 46DVA-F12 943S
Storm Collar 46DVA-SC 953
Vinyl Siding Standoff 46DVA-VSS 950
Wall Strap 46DVA-WS 988
Wall Pen Heat Shield (Wall Thimble) 46DVA-WT 942
