The Contemporary by Blaze King Owners Installation and Operation Manual
HIGH ALTITUDE INSTALLATION
When installing this appliance over 4500 ft (1372 m) above sea level in Canada, the appliance must
be properly de-rated and installed according to local codes. In the absence of local codes, install in
accordance with CSA B149.1, in Canada. In the US for installations above 2000ft the appliance
must be installed in accordance with the current National Fuel Gas Code, ANSI Z223.1/ NFPA 54
(see page 26).
Contemporary - Stove Dimensions
WIDTH 22” / 559mm
HEIGHT 29.5” / 749mm
DEPTH 18” / 457mm
MODEL Contemporary Natural Gas (NG) Propane (LP)
Manifold Pressure
1.6 - 3.5 in. w.c. (0.43 - 0.87kPa) 6.3 - 10.0 in. w.c. (1.57 - 2.49kPa)
Min. Supply Pressure for
Purpose of Input Adjustment
5 in. w.c. (1.24 kPa) 12.0 in. w.c. (3.0 kPa)
Max. Supply Pressure for
Purpose of Input Adjustment
7.0 in. w.c. (1.8 kPa) 14.0 in. w.c. (3.5 kPa)
Orifice Size
37# DMS 53# DMS
Nominal Input Rating
27,000 BTU/hr 27,000 BTU/hr
Minimum Input Rating
19,000 BTU/hr 20,000 BTU/hr
Operating Efficiency (fans off*) 82% 82%
Altitude
0 - 4,500 ft. (0 - 1372 m) 0 - 4,500 ft. (0 - 1372 m)
Primary Air Opening
1/8 in (Minimum). 1/8 in (Minimum).
Electrical Rating
120 V.A.C. System 120 V.A.C. System
Circulating fan
Variable Speed Variable Speed
Vent System
4” x 6-5/8” 4” x 6-5/8”
Log Set
Ceramic Fiber (2 Piece) Ceramic Fiber (2 Piece)
A manufactured home (USA only) or mobile home OEM installation must conform with the
Manufactured Home Construction and Safety Standard, Title 24CFR, Part 3280. When such a
standard is not applicable use the standard for Manufactured Home Installations, ANSI/NCSBCS
A225.1, or Standard for Gas Equipped Recreational Vehicles and Mobile Housing, CSA Z240.4.
Specifications
* Slightly Higher Efficiency may be obtained with fans on.
