Maintenance
PART NAME PART #
Gas Valve convertible—SIT SIT0820652
Piezo igniter with nut SIT0073952
Relief Plate gasket 36” x 5/8” dense
gasket
Burner Orifice Propane #53
Burner Orifice Nat. Gas #37
2 piece log set M0814
Brick Panel Right 6062
Brick Panel Left 6063
Brick Panel Rear 6061
Brick Panel Base 6060
Brick Panel base Right 6103
Brick Panel Base Left 6104
Brick panel clip 6065
Rheostat Fan Control w/off 0136
Door Assembly—Black Z6018P-C
Door Assembly—Gold Z6018G-C
PART NAME PART #
Main Door Rope Seal 0188
Fan assembly 0719B
ON/OFF rocker switch 0725
Spark igniter electrode 0738B
Thermopile generator 0721A
Thermocouple 0842VC
Pilot assembly Z6003P
Burner tray Assembly Z9919
Orifice spring 0723
30% Vent Restrictor 6082
60% Vent Restrictor 6094
70% Vent Restrictor 6095
75% Vent Restrictor 6097
Bag of Fiber Embers 0745
LPG Conversion Kit—SIT
(0-2000ft USA / 0-4500ft Canada)
Z0760P
Fan Switch 130F 1144AA
Replacement Parts List
GOLD PLATING:
1. Gold plating requires little maintenance and needs only to be cleaned with a soft damp cloth. Do not use any
abrasive cleaning materials.
2. Avoid fingerprints on gold. Wipe off fingerprints before firing.
DOOR :
Check the gasket to see that it is still forming a seal. Replace gasket if there is any sign of wear.
VIEWING GLASS REPLACEMENT:
This appliance is supplied with high temperature 5mm high temperature ceramic glass that will easily withstand the heat
your unit was designed to produce. In the event the glass breaks, contact your dealer or BLAZE KING to arrange for
your glass to be replaced / repaired. (see page 22)
REMOVING THE BLOWER:
1. Turn the gas off to the unit.
2. Turn off/unplug the electric supply.
3. Remove the back panel on the pedestal.
4. Remove the 4 screws on the back panel that attach the blower.
5. Replacing the assembly is the reverse of the above instructions
