PAGE 19
OM-8003 & 8004
Date Printed: Tuesday, February 08, 2005
Revision Date: 06-12-03
FOR YOUR SAFETY - READ BEFORE LIGHTING
WARNING
If you do not follow these instructions exactly, a fire or explosion
may result causing property damage or personal injury.
A. This appliance has a pilot that is lit with a push button Piezo lighter. When lighting the pilot, follow these
instructions exactly.
B. BEFORE LIGHTING smell all around the appliance area for gas. Be sure to smell next to the floor because
some gas is heavier than air and will settle on the floor.
WHAT TO DO IF YOU SMELL GAS:
* OPEN WINDOWS
* DO NOT TOUCH ANY ELECTRIC SWITCH; DO NOT USE ANY PHONE IN YOUR
BUILDING
* EXTINGUISH ANY OPEN FLAME
* IMMEDIATELY CALL YOUR GAS SUPPLIER FROM A NEIGHBOR'S PHONE
AND FOLLOW THE GAS SUPPLIER’S INSTRUCTIONS
* IF YOU CANNOT REACH YOUR GAS SUPPLIER, CALL THE FIRE DEPARTMENT
C. Using only your hand, push in or turn the gas control knob. Never use tools. If the knob will not push in, turn
by hand. Do not try to repair it; call a qualified service technician. Force or attempted repair may result in a fire or
explosion.
D. Do not use this appliance if any part has been under water. Immediately call a qualified service technician to
inspect the appliance and to replace any part of the control system and any gas control which has been under
water.
LIGHTING PREPARATION
LIGHTING INSTRUCTIONS ROBERTSHAW OR HONEYWELL VALVE
(See Page 21 For Valve Diagram)
1. STOP! Read the safety information above.
2. Set the optional wall thermostat to lowest setting, and turn appliance switch off.
3. Controls are accessed by opening the right side door panel.
4. Turn the rocker switch to OFF.
5. Push in the gas control knob slightly and turn clockwise to OFF.
NOTE: The knob cannot be turned from PILOT to OFF unless the knob is pushed in slightly. DO NOT FORCE.
6. Wait five (5) minutes to clear out any gas. If you smell gas STOP! follow step B above. If you do not smell
gas, go the step 7.
7. Turn Control Knob counter clockwise to PILOT position.
8. Depress control knob and push in the Piezo ignitor button. Once pilot ignites, continue to hold the control
knob in for about one (1) minute after the pilot is lit. Release the knob and it will pop back up. Pilot
should remain lit. If it goes out, repeat from step 6.
ATTENTION!
Honeywell valves are equipped with a safety shut off device, once the control knob is
turned off, it will lock into place until the thermopile cools down. (Approx. 3 minutes)
