PAGE 4
OM-8003 & 8004
Date Printed: Tuesday, February 08, 2005
Revision Date: 06-12-03
8003 & 8004 SPECIFICATIONS
NATURAL GAS L P GAS
8003 8004 8003 8004
Input Rating (BTU/hr) 0-610m (0-2000 ft.) Alt. 38,000 38,000 38,000 38,000
Orifice Size (DMS) 0-610m (0-2000 ft.) Alt. 31 31 50 50
Input Rating (BTU/hr) 610-1370m (2000-4500 ft.) Alt. 35,100
(Cdn. only)
35,100
(Cdn. only)
35,800
(Cdn. only)
35,800
(Cdn. only)
Orifice Size (DMS) 610-1370m (2000-4500 ft.) Alt. 32 32 51 51
Unit Comes Factory Equipped For 0-610m (0-2000 ft.) Alt.
Minimum Input (BTU/hr) 20,500 20,500 19,000 19,000
Manifold Pressure (in w.c. / kPa) 3.5 / 0.87 3.5 / 0.87 11.0 / 2.74 11.0 / 2.74
Manifold Pressure - Low Setting (in w.c. / kPa) 1.3 / 0.32 1.3 / 0.32 2.7 / 0.67 2.7 / 0.67
Minimum Inlet Pressure (in w.c. / kPa) 4.5 / 1.12 4.5 / 1.12 12.2 / 3.04 12.2 / 3.04
Please confirm any information you require for installation or service with the approval label on the appliance.
IF THIS APPLIANCE IS NOT PROPERLY INSTALLED, A HOUSE FIRE, OR EXPLOSION MAY RESULT. FOR YOUR SAFETY,
FOLLOW THE INSTALLATION DIRECTIONS. CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND
INSTALLATION REQUIREMENTS IN YOUR AREA. PLEASE READ THIS ENTIRE MANUAL BEFORE YOU INSTALL AND USE YOUR
NEW APPLIANCE. FAILURE TO FOLLOW INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE, BODILY INJURY or DEATH.
CAUTIONS: NEVER vent the appliance to other rooms or buildings. The appliance must be vented only to the outside.
NEVER burn the appliance with the viewing door open.
FIRE EXTINGUISHER:
Every home should have at least one fire extinguisher. An approved Class A-B-C extinguisher should be mounted on the wall near an exit
and close to the appliance, but not so close that accessibility to the extinguisher could be blocked by a fire. Your local Fire Department can
advise you concerning the most appropriate location.
BUILDING AND FIRE CODES, PERMITS AND INSPECTIONS:
The installation of this gas appliance must comply with your local building and fire codes. Always contact your local Building Inspector and/
or Fire Department before begining the installation process. If required, obtain a permit before installation and have the completed
installation inspected. Remember that not complying with building and/or fire codes may jeopardize your homeowner’s insurance.
CHILDREN:
Do NOT allow children to play near the appliance or with the controls. Severe burns may be inflicted by touching the door or glass, the
front, sides or top of the appliance. Train children to stay away from the appliance, and never leave children unattended in the room when
the appliance is in operation.
SMOKE DETECTORS and CARBON MONOXIDE DETECTORS (CO - DETECTORS):
Install at least one smoke detector on each floor of your home to ensure your safety. It should be located away from the gas appliance and
close to the sleeping areas. Follow the smoke detector manufacturers placement installation and maintenance instructions. Your local Fire
Department may provide assistance in selecting smoke detectors and CO-detectors. It is strongly recommended, for your family’s
protection, that a CO-detector be placed in all homes that utilize gas in any form.
THE APPLIANCE AREA MUST BE KEPT CLEAR FROM COMBUSTIBLE MATERIALS, GASOLINE AND
OTHER FLAMMABLE VAPORS OR LIQUIDS.
The Blaze King Vented Gas Fireplace Heater has been tested, certified,
and listed byITS/ WARNOCK HERSEY INC., Middleton, WI, 53562 for USA
to ANSI Standard Z21.88-1998*CSA 2.33-M98
Gas appliances must be tested and certified by a nationally recognized
testing and certification agency to ANSI Gas Appliance Safety Standard.
Freestanding Firebox Shroud
Width 26” 27.5” 43”
Height 33-1/4” 23” 29.5”
Depth 19” 22.5” 2”
Weight 180 116 40
SAFETY NOTICE
