until the Sensor Unit consistently and only flashes when the black mark
passes the Sensor Head. After 2 minutes the Sensor Unit will stop
flashing in order to maximize battery life.
Once the Sensor Arm is properly aligned continue with section 5.7 –
Synchronizing the Display and Sensor Units.
5.6. Electronic Meter Installation
Depending on the electronic meter type you have, the Sensor Unit may need
to be reconfigured. Electronic meters have an optical output that flashes
invisible light through an optical port in a specific pattern that indicates how
much electricity is being consumed at any point in time. The PowerCost
Monitor Sensor Unit will detect this light output automatically.
Some electronic meters have their optical port on the top, in which case the
Sensor Unit will need to be reconfigured. Other meters have their optical
ports on the front. Refer to figure 5.8 to help determine the type of electronic
meter you have.
Figure 5.8 – Top-Mounted and Side-Mounted Electronic Meters
5.6.1. Top-Mounted Electronic Installation
If you have a top-mounted mounted meter follow the steps below exactly as
outlined to ensure that your PowerCost Monitor™ works properly. Be sure to
