bring your tools and your Display Unit to your utility meter before starting the
installation process. For best results, install your Sensor Unit on a dry day
using the following procedure:
1. Reconfigure your sensor unit by opening the Sensor Arm latch fully and
gentle pulling the Sensor Arm all the way out. Refer to figure 5.9 for a
pictorial view of the reconfiguration process.
2. Insert the wired end of the Sensor Arm up through the Sensor Arm latch
opening from the bottom.
3. Gently tuck the Sensor Arm down into its holster in the bottom cavity of
the Sensor Unit. Close the Sensor Arm latch.
4. Locate your household utility meter. The meter may be located outdoors
or indoors. If the glass on the utility meter is dirty, wipe it clean with a
damp cloth.
5. Adjust the sensor mounting strap by turning the adjustment screw
several turns with a flat head screwdriver until it is approximately 15cm
(6 inches) in diameter.
6. Fit the Sensor Unit over utility meter as shown in figure 5.10 below.
Ensure that it is seated as far back on the utility meter glass dome as
possible and centered on the top of the meter.
Figure 5.9 – Sensor Unit Reconfiguration (coming)
