3.3.2 Wiring Interface Instructions
Table 3-4
Minimum wire size:
12AWG
Minimum wire size:
10AWG
Standard
accessories
BAT+: to the battery
BAT+ terminal
BAT-: to the
battery BAT- terminal
Standard
accessories
Outdoor multi-core
copper cable
Outdoor multi-core
copper cable
Minimum wire size:
6AWG
Minimum wire size:
6AWG
Outdoor multi-core
copper cable
Outdoor multi-core
copper cable
BACKUP
G
L1
N
L2
L1
N
L2
G
GRID
Terminal
Type of Cable
Required
Description
Cable specification
PV1+: to the positive
terminal of solar panel
PV1-: to the negative
terminal of solar panel
PV1 PE: PV1 grounding
PV2+: to the positive
terminal of solar panel
PV2-: to the negative
terminal of solar panel
PV2 PE: PV2 grounding
