Bluetti EP800 - B500 Battery Module; Battery Introduction and Overview

12.795in(325mm)
13.307in(338mm)
25.039in(636mm)
Left Right
4. B500 Battery
4.1 Introduction
The B500 battery energy storage system is designed for residential and light
commercial use. Single B500 battery pack has a capacity of 4.96kWh. BLUETTI
EP800 supports 4 *B500 units for a whopping 19.84kWh.
The B500 comes with a reliable battery management system (BMS) with a
multi-stage architecture that provides real-time detection of the battery pack's
voltage, current and temperature, protecting the system from overvoltage, under-
voltage, overcurrent, overtemperature and undertemperature. At the same time,
the redundancy design provides unprecedented safety and stability for the B500
battery energy storage system.
4.2 Overview
4.2.1 Appearance
Table 4-1
4.2.2 Dimensions
Table 4-2 (Unit: in/mm)
Front Right
JUST POWER ON 29
