Plastic housing (PV- Input)
Metal core (PV- Input)
11
12 1
2
Black protection cover (BAT- Input)
(Pre-installed on EP800 inverter)
MC4 wrench
6
2
2
2
10
16
17
18
19
M6*12 screw
(For bracket, pre-installed on EP800 inverter)
M5*10 screw
(4 for fixing device to the bracket,
2 for PV grounding)
M4*10 screw
(For exterior trim)
M8*60 expansion bolt
13 1
1414
Red protection cover (BAT+ Input)
(Pre-installed on EP800 inverter)
M4*12 screw (8 for BAT+/- protection cover,
6 for AC cable protection case,
pre-installed on EP800 inverter)
215
M8*12 screw
(For battery power cable)
7
3
20
21
RNB8-6S OT terminal (AC)
RNB3.5-5S OT terminal (PV Grounding)
22
Self-tapping screw, ST8×40
