BMC Timemachine - Front Seatpost Configuration

Front Seatpost Configuration
1 Seatpost
2 Storage Box Cover
3 Rubber Link
4 Storage Box (optional)
5 Seatpost Clamp Nut (x2)
6 Seatpost Clamp Bracket & Bolts (x4)
7 Storage Box Fixation Mount & Bolt
1
2
3
4
5
6
7
Riders electing to not use the storage box can install an
optional cover in the vacant rear seatpost mounting hole.
