Brake Booster Components
1 Upper bolt
2 Washer
3 Cable interface
4 Brake Booster – Upper (R)
5 Main Socket Bolt
6 Brake Booster – Lower (F)
7 Housing boss (x2)
8 Brake Booster Box
9 Countersunk Bolt
10 Support
11 Bushing
12 Cable Stopper (x2)
13 Cable Stop Nuts (x2 per stopper)
1
2
3
4
5
3
6
7
8
9
10
11
12
13
12
13
11
Brake Boosters will come pre-assembled on the Support (10) on all complete bikes and framesets.
