BMC Timemachine Assembly Manual

V-Cockpit Assembly – Extension Brackets
1. Insert the Extension Clamp into the Bracket (once installed,
the slider will hold the Extension Clamp in place)
2. Install the Slider into the Bracket and insert the Slider
Fixation Bolts
3. Tighten up to 12 Nm
Step 1
Steps
2 & 3
