Brake housing & Cable Installation
Frame
Size
Brake Casing Length
Front Brake Rear Brake
S 120mm 710mm
M-S 135mm 740mm
M-L 135mm 770mm
L 175mm 840mm
Failure to follow these prescribed lengths will significantly increase
the difficulty of achieving proper brake function and smooth feel.
Pre-cut brake housing lengths:
