Brake Housing & Cable Installation
1. Starting at the Brake Booster Box, route the brake housing through
the Headset Bolt using the supplied flex-noodle
2. Pass the front brake housing directly through the head tube to the
mounted brake caliper
3. Pass the rear brake housing in to the frame at the downtube junction
and pass it underneath the bottom bracket area to the mounted brake
caliper.
Step 1
Step 2
Step 3
