Finishing Assembly – Flat-Cockpit Mechanical
1. For mechanical shifting, the Flat Cover must be modified for
cable and housing entry
2. Using the two pre-drilled indents (image), drill from the back side
of the cover to create 5mm holes
3. Install Flat Cover, making sure to prevent any unwanted
pinching of electronic wires.
4. Install Flat Cover Rear Bolts to 5Nm
5. Install Flat Cover Front Bolts to 10Nm
Steps
3 - 5
Step
1 & 2
