The differences in the cable routing exist
only between the brake lever and the brake
booster (in blue).
The rest of the cable routing (in green)
between the brake lever and the brake
caliper, needs no modification.
Routing the front break on the right side of the TM01 is possible.
The following pages demonstrate how to change the brake cable
routing to assemble the front brake for right-handed shifting.
In green the standard routing from
the brake booster to the brake caliper.
In blue the new routing.
Right hand front brake assembly
