BMC Timemachine - Front Brake Cable Routing

Fork Installation
1. Mount the Lower Conical Ring on the fork – slot pointing forwards.
2. Place the Lower Bearing into the frame – grease on all contact points
3. Insert the fork into the frame
4. Place the Upper Bearing into the frame – grease on all contact points
Step 1
Step 2
Step 3
Step 4
