4. Remove the adhesive protection from the Cover Plate and put it in
its dedicated recess onto the Extension Bracket (Right/Left-
specific)
V-Cockpit Assembly – Extension Brackets
5. Install the Extension Clamp Bolt into the Slider only
2 complete rotations
6. Repeat steps 1-5 for the other side
The Carbon Extensions are now ready to be installed in later steps
Step 4
Step 5
