BMC Timemachine - P2 p Seatpost Clamp Installation; P2 p Seat Clamp Parts Overview

1. Install Sliders into the corresponding Base Bar (R & L)
2. Place the Spherical and V Washers onto the Slider
Fixation Bolts (x2)
3. Insert the Slider Fixation Bolts through the Base Bar
holes and the Slider longholes
4. Install the Slider Fixing Bolts into the corresponding
bridge parts (R & L) and pre-tighten them slightly (just
ensure the parts do not slide anymore)
V-Cockpit Assembly – Base Bar
1
2
3
4
