BMC Timemachine - Page 59

Finishing Assembly – V-Cockpit Extensions
1. Install properly cut extension in to Extension Clamp
2. Tighten Extension Bolt to 4Nm
3. Install Extension End Caps (end caps have a slotted bottom for
passing electronic wires)
Step 2
Step 3
