YH-600B Pro User Manual V3.0
18 / 88
Effort Lead CableRespiration Effort Belt Respiration Box
Fig 1-7 Connecting the respiration kit
Step 1: Connect the effort lead cable and respiration effort belt;
Step 2: Fasten the respiration effort belt around the body;
Step 3: Insert the effort lead cable into the holes of the small
respiration box, and hang the respiration kit on the respiration
effort belt.
10.1.4 Wearing the Airflow Cannula
As Fig 1-8 shows, place the two prongs of the cannula in the
nostrils, hook the cannula around the ears, and push the slide
fastener upward to fix the cannula on the head. Insert the other
end of the cannula into the air pathway interface of the respiration
kit.
