YH-600B Pro User Manual V3.0
26 / 88
Waveform indicates the occurrence of a
snore
Thoracoabdominal
Respiration:
Chest or abdominal breathing
fluctuations
The user’s body position when the device
is in use
Note:
①
The pulse oximeter equipment is calibrated to display functional
oxygen saturation.
②
The sampling rate of the SpO
2
signal is about 50 Hz, and the
update rate of the frame is 1 Hz. So even there are some filtering
methods to process the SpO
2
data, it will not delay for a relative
long time to the displaying data.
③
The waveform of the signal is non-normalized so that the
software can provide to the operator that the pulse rate value
displayed is potentially incorrect. However, YH-600B Pro which
does not store the waveform data just keeps waveform updating
to give the implication of the detector in working state.
④
If the pulse oximeter sensor is in an abnormal state, the value
of SpO
2
will be blank.
⑤
The value of SpO
2
and PR is calculated by the average of the
former eight pulse waveforms.
10.2.4 Accessing the “Setup” Interface
From the standby interface, press the Shift Button to switch
the yellow frame to the “Setup” icon . Press the On-Off / OK
