BMGi E8 - Installation Examples; Single Swing Gate Setup Example

Single Swing Setup Example
Installations vary slightly on different types of gates
CAUTION SIGN
GATE STOP
GATE BRACKET
ACTUATOR ARM
PRIMARY BRACKET
CONTROL BOX
SECONDARY
BRACKET
CABLE TO:
SOLAR PANEL
(10M CABLE
SUPPLIED)
OR TRANSFORMER
(CABLE NOT
SUPPLIED)
POWER CABLE
MOTOR 2 (MAIN)
CONDUIT
FENCE POST SET
IN CONCRETE
10
