BMGi E8 - Installing Gate Bracket

Pull-to-Open Setup
Round Gate Bracket
Optional extra
Standard
Gate
Bracket
Round
Gate
Bracket
Round gate bracket setup examples
Standard
Gate
Bracket
Release
Bolt
Actuator
Arm
Actuator arm installed onto standard
gate bracket or round gate bracket
Standard Gate Bracket
Supplied in kit
How to clamp gate bracket
DO NOT have the release bolt done
up tight as this will make for a
difcult release of the actuator arm
and may cause jamming or binding
