Installing Primary and Secondary post brackets
Now that you have your gate and post bracket points marked along with your
arm pivot point, you can now go ahead and attach these brackets into position
(clamp rst if preferred).
Once you have secured the primary post bracket (or round post bracket) you
can then slide the secondary bracket between the middle gap of the primary
wall bracket. Do not tighten the nylon nut yet.
Note: these brackets should be checked on a regular basis.
Square Post
Round Post
Primary Post
Bracket
Secondary
Bracket
Round Post
Bracket
(optional extra)
Secondary
Bracket
Note: Bracket modications may be required due to your post and
hinge setup. Contact your dealer if you require further assistance.
Pull-to-Open Setup
