BMGi E8 - Double Swing Gate Setup Example

Double Swing Setup Example
Installations vary slightly on different types of gates
GATE BRACKET
CABLE TO:
SOLAR PANEL
(10M CABLE
SUPPLIED)
OR TRANSFORMER
(CABLE NOT
SUPPLIED)
CONDUIT
POWER CABLE
FENCE POST SET IN
CONCRETE
JUNCTION BOX
ACTUATOR ARM
CAUTION
SIGN
PRIIMARY BRACKET
CONTROL BOX
ACTUATOR ARM
POWER CABLE
GATE STOP
SECOND BRACKET
MOTOR 1
MOTOR 2
(MAIN)
