Control Board Specications and Details
Ant Antenna for control board
2Side Terminal for external device of controlling double gates
Com Common for external device
1Side Terminal for external device of controlling single gate ( Motor2)
Card Terminal for external device for double gates OPEN ONLY
Com Common for external device
IR Terminal for Photo beam sensor
Com Common for Photo beam sensor
12V+ Power supply for external device
Bat Terminal for 12V Battery
Lamp Terminal for lamp
Lock Terminal for lock
Control Board
State Indicator Steady on: Indicating that the system is working
normally Blinking at 1Hz: indicating that the system is in
the mode of auto close or travel learning.
Fast blinking: The system is error.
Terminal Indicator On: The terminal is ON.
Off: The terminal is OFF
Instructions for Indicator
DEC used for lowering values
FUNC used for entering the menu and storing the settings
INC used for increasing values
RF Learn used for learning or removing remotes
Instructions for button
